pmx-gc-stats

Stats about Node.js V8 garbage collector are exposed in PM2 for each GC type executed using PMX probes

Usage no npm install needed!

<script type="module">
  import pmxGcStats from 'https://cdn.skypack.dev/pmx-gc-stats';
</script>

README

pmx-gc-stats

Stats about Node.js V8 garbage collector are exposed in PM2 for each GC type executed using PMX probes.

Table of Contents

Presentation

Stats about Node.js V8 garbage collector are exposed in PM2 for each GC type executed using PMX probes.

For improvement and maintenance of the code originally made here: pmx-gc-stats-sum

Requirements

  • Any PM2 version installed globally:

npm install -g pm2

Installation

npm install pmx-gc-stats

npm i -S pmx-gc-stats

If you have issues with node-gyp when installing the module, install the latest version of NPM:

npm i -g npm@latest

Technical information

Node.js

  • Language: JavaScript ES6/ES7
  • VM: Node.js >=10.0.0

Tests

Command to run all tests:

npm test

Linting

ESLint with Airbnb base rules. See Airbnb JavaScript Style Guide.

npm run test:lint

Unit

Mocha and Chai.

npm run test:unit

PM2

To launch the testing app:

npm run start:pm2

To show PM2 metrics:

pm2 monit

pm2 show test-app

To stop the testing app:

npm run stop:pm2

Usage

Import

It is necessary to require this package before any other module launches.

pmx-gc-stats module exports one function named pmxGcStats.

const pmxGcStats = require('pmx-gc-stats');
pmxGcStats();

// or directly calling the function
require('pmx-gc-stats')();

pmxGcStats([options])

Stats about Node.js V8 garbage collector are exposed in PM2 for each GC type executed using PMX probes.

  • options<Object> Default: undefined

    • types<Array> GC types selected as <Integer>

      • 1
      • 2
      • 4
      • 8
      • 15

      Default: all of the above values

    • probes<Array> probes selected as <String>

      • count
      • pause
      • total-heap-size
      • total-heap-executable-size
      • used-heap-size
      • heap-size-limit
      • total-physical-size
      • total-available-size
      • malloced-memory
      • peak-malloced-memory

      Default: all of the above values

  • Returns: undefined

Examples:

const pmxGcStats = require('pmx-gc-stats');
pmxGcStats();

// or directly calling the function
require('pmx-gc-stats')({
  types: [1, 2, 4],
  probes: ['count', 'pause', 'total-heap-size' ],
});

PMX probes

pmx-gc-stats exposes PMX probes showing the Node.js V8 garbage collector statistics below visible in PM2.

There are 5 different garbage collector types and for each type 9 probes are exposed.

Metrics format are gc-type-{type}-{suffix}.

GC types

type description
1 Scavenge (minor GC)
2 Mark/Sweep/Compact (major GC)
4 Incremental marking
8 Weak/Phantom callback processing
15 All

Probes suffixes

For each GC type:

suffix type description unit
count count Number of times this GC type has been executed -
pause sum Total pause time from start to end of GC using hrtime() nanoseconds
diff-total-heap-size sum Total size difference allocated by V8 for the heap from the last stats events; this can grow if usedHeap needs more bytes
diff-total-heap-executable-size sum Total size difference for compiled bytecode and JITed code from the last stats events bytes
diff-used-heap-size sum Total size difference in use by application data from the last stats events bytes
diff-heap-size-limit sum Total difference from the last stats events regarding the absolute limit the heap cannot exceed bytes
diff-total-physical-size sum Total committed size difference (node 0.11+) from the last stats events bytes
diff-total-available-size sum Total available heap size difference (node 4+) from the last stats events bytes
diff-malloced-memory sum Total dynamically allocated memory size difference from the last stats events bytes
diff-peak-malloced-memory sum Total dynamically allocated memory size peak difference from the last stats events bytes

Example

GC type 15
gc-type-15-count
gc-type-15-pause
gc-type-15-diff-total-heap-size
gc-type-15-diff-total-heap-executable-size
gc-type-15-diff-used-heap-size
gc-type-15-diff-heap-size-limit
gc-type-15-diff-total-physical-size
gc-type-15-diff-total-available-size
gc-type-15-diff-malloced-memory
gc-type-15-diff-peak-malloced-memory

Display probes

pm2 monit

pm2 show your-app-name

Development

All contributions are greatly welcome :)

Please follow Git flow, ES6/7, ESLint Airbnb base rules.

Licence

pmx-gc-stats is released under the MIT license.
